Residential 25KA Weichai Diesel Generator With WP2.3D25E200 Engine

Name: Residential 25KA Weichai Diesel Generator With WP23D25E200 Engine
Brand: Weichai
Price: 1 USD

Residential 25KA Weichai Diesel Generator With WP2.3D25E200 Engine Manufactures

Brand Name : Weichai

Model Number : BWC series

Certification : CE

Place of Origin : China

MOQ : 1 set

Supply Ability : 500pcs per month

Delivery Time : 30 days

Packaging Details : Plywood

Canopy : Customized

Rated voltage : 400/230V, 110-480V, 220V / 380V, 110V / 240V, 380V

Warranty : 12 Months/1000 Hours

Alternator : Marathon, Stamford, SLG/Stamford/Marathon/Meccatle/Leroy-somer, Stamford or Newtec, Engga

Type : Silent(super Silent)or Open, Silent, etc, In-line/6-Cylinder/4-Stroke/4-Valve/19L, Soundproof Canopy(Silent)

Product name : Diesel Genertor, generator 250kw, Powered by Cummins diesel generator, Standby use power diesel generator 1000kw

Control panel : LCD Digital Display, Deepsea, ComAp, Deepsea / ComAp / Harsen / Smartgen 6110, Smartgen

Color : Customers' Requirement

Frequency : 50/60HZ

Rated power : 25KA

Output type : AC Single/Three Phase

Engine : Original Weichai

Controller : Deepsea/Smartgen/etc

Cooling method : Water-cooling System

Application : Indursty bank etc

Contact Now

Diesel generator set powered by weichai engine 25KA with WP2.3D25E200

Products Features:
1.We cooperate with famous diesel engine Powered by original Baudouin engine.
2. Equipped with 50°C radiator with fan, enough engine cooling system guarantee long time working
3. Equipped with advanced generator set control system, ATS system, remote control system, parallel operation system, optional control model, Deep sea, Smartgen , ComAp ,
4. Generator set use High-quality steel are thickness canopy -- 2MM to 6MM
5. High protect class control box and power output box. IP55, Waterproof, Electric leakage protect, Breaker,High water temperature protection,Engine oil alarm, Over load protection, Overfrequency protection, Emergency stop unit
6. New design of turn-back type for air inflow & air outlet which can reduce the noise and improve engine efficiency.
7. All new design for diesel generator set of Silent, Supper silent, Soundproof, Trailer type, Container type.

Safety - Stability - Economy - Reliability Power
Our generator set compliance with all main standards, such as : GB/T2820, ISO8528,IEC34, CE, EPA Tier4 standard

Controller System
Standard AMF control panel, including digital LED genset control model: HGM6120U, DSE7320, DSE

Gensets					Technical Data of Diesel Engine(50hz/1500rpm)		Alternator(50hz/1500rpm)	Size
Model	Gensets power(KW/KVA)				Engine model	Engine power(kw)	BOBIG	Open type (MM)	sounproof type (MM)
Model	Prime		Standby		Engine model	Prime	BOBIG	Open type (MM)	sounproof type (MM)
BWC28	20	25	22	28	WP2.3D25E200	23	BW-184F	14506201125	19508501050
BWC33	24	30	26	33	WP2.3D33E200	30	BW-184G	14506201125	19508501050
BWC41	30	38	33	41	WP2.3D40E200	36	BW-184H	15006201150	20008501050
BWC50	36	45	40	50	WP2.3D48E200	44	BW-224C	16006201150	22008801150
BWC55	40	50	44	55	WP2.3D48E200	44	BW-224D	16006201150	22008801150
BWC69	50	63	55	69	WP4.1D66E200	60	BW-224E	18207801200	25009701200
BWC83	60	75	66	83	WP4.1D80E200	72	BW-224F	19007001200	25009701200
BWC110	80	100	88	110	WP4.1D100E200	90	BW-274C	20008001500	275010401350
BWC138	100	125	110	138	WP6D132E200	120	BW-274D	23508001580	320012001660
BWC165	120	150	132	165	WP6D152E200	132	BW-274E	25008001760	340012501750
BWC206	150	188	165	206	WP10D200E200	182	BW-274G	290011201450	380012901900
BWC248	180	225	198	248	WP10D238E200	216	BW-274J	290011201450	380012901900
BWC275	200	250	220	275	WP10D264E200	240	BW-274K	290011201450	380012901900
BWC344	250	313	275	344	WP12D317E200	288	BW-314DS	310010502100	390014001950
BWC413	300	375	330	413	WP13D385E200	350	BW-314F	310010502150	420016002250
BWC413	300	375	330	413	WP13D405E200	368	BW-314F	310010502150	420016002250
BWC454	330	413	363	454	WP13D405E200	368	BW-354C	310010502150	420016002250
BWC495	360	450	396	495	WP13D440E310	400	BW-354C	360015002460	450017002000
BWC550	400	500	440	550	WP13D490E310	440	BW-354D	360015002460	450018102360
